Introduction
YVP series motor is totally enclosed,compulsive special used motor.By using variable-frequency motor of different poles,it can achieve stepless speedgoverning when the wide speed range is 100rpm-3550rpm.It is applied to the fields of fan,pumps,pipeline automation equipments and machine tools(such as numerical control machine tool and machining center)in the industries of metallurgy,chemical,textile,pharmacy,printing and so on.
Technical Paramenters
1.Basic characteristics
Centre height of frame size:80-355mmPower range:0.55-315kw
Rated voltage and frequency:380V 50HZ
Frequency variable range:3~60(75)Hz or 3~100Hz
Protection class:IP54Insulation class:155 (F)
Duty type:S1(continuous)
Type of cooling:IC416
pole:2P、4P、6P
Power 55kw and below is star-connection;
Power above 55kw is delta-connection.
2.Conditions of usage
Working ambient temperature:-15~40 degree centigrade.
The altitude:not above 1000m.
If any special please mention when placing order.
Frame size、Pole & Frequency Table
Axial-flow fan power, current, air flow Table
